Full size Industrial Motherboard LGA1155 PICMG1.0

Full size Industrial Motherboard LGA1155 PICMG1.0

B75 Chip full size card motherboard, 2LAN 2COM 8USB



Full size Industrial Motherboard LGA1155 PICMG1.0



Product Introduction

This outstanding multi-function embedded motherboard is integrated with the Intel LGA 1155 architecture Celeron, Pentium, i3 i5 i7CPU, Intel B75 chip to deliver stunning UHD 4K resolution and fast 3-D and video playback for graphics-intensive applications. To ensure stable and reliable operation, the high-performance Intel® Core™-based industrial micro ATX motherboard supports a watchdog timer and hardware monitoring features. Boasting a robust power design, comprehensive cooling solutions and intelligent tuning options, the motherboard provides daily users and DIY PC builders a range of performance tuning options via included software and hardware.



Product Features

■ Support for Intel LGA 1155 architecture Celeron, Pentium, i3 i5 i7CPU, Intel B75 chip
■ Support for 2 DDR3-1066/1333/1666 memory up to 16GB
■ 2LAN 2COM 8USB
■ PICMG1.0 full length
■ LPT pin on board
■ Support for watchdog, diskless startup, network wakeup, power on and timing

Full-Length Card Motherboard

System

CPU/GPU

Support for Intel LGA1155 architecture i7, i5, i3, Pentium, Celeron.

System on Chip

Intel B75

Memory

2×memory slot, supports maximum DDR3 memory to 16GB

Storage

4×SATA

Sound card

Realtek ALC662,  supports 5.1 channels

Ethernet

2×Realtek RTL8111E network card chip, PCI-E bus gigabit network card

Display

CPU integrated graphics card

LVDS

VGA

Double display

None

COM

2×COM RS-232

USB

8× USB

BackplaneI / O

2RJ45,VGA,PS/2KM

BoardI / O

2×COM pin,8× USB pin,1× LPT pin,1×front panel pin,,1× buzzer

1× front audio pin,1× CLR_CMOS pin

1× 24PIN ATX  power outlet, 1×4-PIN CPU power outlet,

1× CPU fan power supply socket,,  1×system fan power outlet

Expand

PICMG1.0 (PCI bus+ISA bus)

Specific function

Support for watchdog, diskless startup, network wakeup, power on and timing



Mechanical & Environmental

Power supply

ATX

Heat dissipation

Fan

Size(L×W)

338mm×122mm

Working temperature

-10~55℃

Storage temperature

-40~75℃

Environmental humidity

0~95%air humidity,no condensation

Packing list

ATX-G41V2NA-6 motherboard×1;   SATA data line×2;   COM line×2;   parallel line×1;   drive disc×1

USB line×1; sound card line×1



Application area

Industrial control computer, industrial automation, numerical control equipment, etc.



Order information

FSB-G41V2A

B75 Chip full size card motherboard, double network 2 series 8USB



Our Advantages

1. As a professional manufacturer/ OEM Factory and supplier of Mini PC/ motherboard,firewall appliance over 15 years,Affinicate member of intel League.gain greatly supports from intel.And we win our customers with good quality,best service and factory price.

2.Our products are 100% original and have strict QC inspection before shipment.

3.Professional and efficient sales team to serve for you diligently.

4.Sample order is welcomed and will be delivered within 1-3 days.

6.We support Trade Assurance to ensure On-time shipment and product quality.

7.We provide OEM/ODM service according to your requirements.

8.We provide 2 years maintenance warranty for our products.



FAQ

1.Q: What's the Minimum Order Quantity(MOQ)?

A: Just 1 piece is OK.

2.Q: Are you a factory or a trading company?

A: We are one of the professional computer manufacturers located in Shenzhen, China.

3.Q: What about the after-service?

A: Two-year warranty except human error. As for the following 2 years, we can repair it for free, but charge for parts is needed. please contact us at any time when necessary. We besides our professional technicians are at your service.

4.Q: Can you provide DIY/OEM/ODM service?

A: Yes, please advise the CPU, memory, SSD or HDD, WIFI, interface ports and OS, the package box and housing(outer shell)as you wish, prices will be varied according to the quantity and specification.
